Mounting type

Lock screw

Connector type

Cabel RG174 , SMA-J / FAKRA

Dimensions (mm)

80.5 x φ29.5

Operating temperature

-40°C to +85°C

Antenna and electrical specifications

Standards

4G/3G/2G

Frequency (MHz)

824~960 , 1710~2690

VSWR

<2.0 , <2.5

Peak Gain (dBi)

-0.5~2.5 , -1.0~3.0

Impendance (Ohm)

50

Max Input Power (W)

5
