Mounting type

Adhesive

Connector type

IPEX MHF1 Standard

Dimensions (mm)

45.4 x 10 x 0.25

Operating temperature

-40°C to +85°C

Antenna and electrical specifications

Standards

4G/3G/2G

Frequency (MHz)

824~960 , 1710~2690

VSWR

<4.5 , <2.8

Peak Gain (dBi)

-0.5~2.0 , 1.0~5.0

Impendance (Ohm)

50

Max Input Power (W)

5
