Mounting type

Adhesive

Connector type

IPEX MHF1 Standard

Dimensions (mm)

135 x 0.85 x 1.0

Operating temperature

-40°C to +85°C

Antenna and electrical specifications

Standards

Wifi/2.4G/5.8G/BT

Frequency (MHz)

2400~2500 , 5100~5900

VSWR

<1.5 , <1.7

Peak Gain (dBi)

-1.0~3.0 , 2.0~5.0

Impendance (Ohm)

50

Max Input Power (W)

5
