Mounting type

Adhesive

Connector type

IPEX MHF1 Standard

Dimensions (mm)

112 x 16.5 x 1.0

Operating temperature

-40°C to +85°C

Antenna and electrical specifications

Standards

5G/4G/3G/2G/NB-IoT

Frequency (MHz)

600~6000

VSWR

<3.5

Peak Gain (dBi)

-3.0~5.0

Impendance (Ohm)

50

Max Input Power (W)

5
