Mounting type

Adhesive

Connector type

IPEX MHF1 Standard

Waterproof grade

IP67

Dimensions (mm)

φ46 x 16.8(H)

Operating temperature

-40°C to +85°C

Antenna and electrical specifications

Standards

GPS/GNSS/BD/4G

Frequency (MHz)

1559 , 1575 , 1602 , 1710~2690

VSWR

2.1 , 2.45 , 1.17 , <3.5

Peak Gain (dBi)

28±1 , -0.5~3.0

Impendance (Ohm)

50

Max Input Power (W)

5
