General specification | Mounting type |
Lock screw | Connector type | Cabel RG174 , SMA-J / FAKRA | Dimensions (mm) | 55.6 x φ12.5
| Operating temperature | -40°C to +85°C |
Antenna and electrical specifications | Standards | 4G/3G/2G | Frequency (MHz) | 824~960 , 1710~2690 | VSWR | <2.8 , <2.0 | Peak Gain (dBi) | -0.5~2.5 , -1.0~2.0 | Impendance (Ohm) | 50 | Max Input Power (W) | 5 |
|
