Mounting type

Connector Mount

Connector type

SMA

Dimensions (mm)

158 x 17.5 x 13

Operating temperature

-40°C to +85°C

Antenna and electrical specifications

Standards

5G/2.4G//WiFi/BT

Frequency (MHz)

2400~2500 , 5100~5900

VSWR

<2.0 , <2.5

Peak Gain (dBi)

4.5~5.5 , 5.3~6.5

Impendance (Ohm)

50

Max Input Power (W)

5
