Mounting type

Lock screw

Connector type

Cabel RG174 , SMA-J

Dimensions (mm)

φ46 x 16.8(H)

Operating temperature

-40°C to +85°C

Antenna and electrical specifications

Standards

GPS/GNSS/BD/4G

Frequency (MHz)

1559 , 1575 , 1602 , 1710~2690

VSWR

2.15 , 2.48 , 1.16 , <3.5

Peak Gain (dBi)

28±1 , -0.5~3.5

Impendance (Ohm)

50

Max Input Power (W)

5
