Mounting type

Adhesive

Connector type

IPEX MHF1 Standard

Dimensions (mm)

25 x 25 x 6.5

Operating temperature

-40°C to +85°C

Antenna and electrical specifications

Standards

GPS/GNSS/BD

Frequency (MHz)

1559 , 1575 , 1602

VSWR

2.15 , 2.48 , 1.16

Peak Gain (dBi)

25 @ 3.6

Impendance (Ohm)

50
